User's Manual
107
Figure 5-64 Digital channel
Step 2 Configure the settings for the image parameters.
On the digital channel page, click
More
to display more parameters.
Table 5-24 Image settings
Parameter Description
Channel In the
Channel
list, select the channel that you want to configure.
Cable Type
In the
Cable Type
list, select the cable type that the camera uses.
This function is available on select models.
Period
In the
Period
list, select a time period for the image settings. The
image settings will be only used during the selected period.
Effective Time
Enable the effective function.
In the
Effective Time
box, enter the start time and end time for the
period you selected.
Saturation
Adjusts the color shades. The bigger the value, the lighter the color
will become. This value does not influence the general image
lightness.
The value ranges from 0 to 100. The default value is 50. The
recommended range is between 40 and 60.
