User's Manual
6
Figure 2-3 Align screws
Step 4 Turn the device and put in the other two screws, and then fasten all screws to fix the HDD
to the device.
Figure 2-4 Fasten screws
Step 5 Use power cable and data cable to connect the device and HDD.
Figure 2-5 Connect cables
Step 6 Put back the cover and fasten the screws.
