345
5.8.5.3 Display
Display interface includes GUI, TV adjust, Tour and zero-channel encoding.
5.8.5.3.1 Display
Here you can set background color and transparency level. See Figure 5-105.
Figure 5-105
Please refer to the following sheet for detailed information.
There are four options: 1920×1080, 1280×1024(default),
1280×720, 1024×768. Please note the system needs to reboot to
activate current setup.
Please select from the dropdown list.
Here is for you to adjust transparency. The value ranges from 128
to 255.
Check the box here, you can view system time and channel
number on the monitor video.
Check the box; you can optimize the margin of the preview video.
Once you check the box here, system will go to the startup wizard
directly when the system restarts the next time. Otherwise, it will go
to the login interface.
Check the box here, system displays the navigation bar on the
interface.
