Click it and all the OSD info status is displayed as except line feed. Click
to modify the prefix, suffix, content and separator of corresponding OSD
option.
Click it and all the selected OSD info status is displayed as , click to
delete corresponding OSD option.
After selecting some OSD info, click New Line and next OSD info will be
displayed on the picture.
Click OK to finish configuration.
5.4.1.5 Snap Cutout
In this section, plate cutout function will be enabled. The system will cut out the recognized
plate picture and save it under the storage path.
Select Setting > ITC > Snap Cutout.
The Snap Cutout interface is displayed. See Figure 5-32.
Snap Cutout
Select Snap Cutout and Plate, and then plate cutout function is enabled.
Click OK to finish configuration.
5.4.1.6 Extra Device
5.4.1.6.1 Extra Device Status
In this interface, it can view the type, number, status and match status of extra device.
If it is connected to vehicle detector of our company and the com protocol selects vehicle
detector, then it can detect if the associated info and status of vehicle detector is normal.
Select Setting > ITC > Extra Device > Extra Device Status and the interface of Extra Device
Status is displayed. See Figure 5-33.
