Device Installation 15
4 Device Installation
Installation Flow Chart 4.1
VTH installation flow chart is shown in Figure 4-1 Please install VTH in the following steps.
Figure 4-1
 For cable connection, please refer to “2.2 Rear Panel Port“.
 For device installation, please refer to “4.4 Device Installation“.
Open-case Inspection
4.2
Please carry out open-case inspection when receiving the device. Please timely contact our
after-sales service personnel in case of any problems.
Sequence
Item
Content
1
Overall
package
Appearance
Inspect whether there are obvious damages.
Package
Inspect whether there are accidental impacts.
Fittings
Inspect whether fittings are complete.
2
Model
and label
Device model
Inspect whether it is consistent with order
contract.
