Dahua XVR5108HS User Manual

118
Parameters
XVR5104HS
XVR5108HS
XVR5116HS
Audio Port
Audio Input
1-channel RCA port.
Coaxial Audio
Input
N/A
Audio Output
1-channel RCA port.
Bidirectional
Talk Input
Reuse the audio input/output port of the 1
st
channel.
Record
Record Mode
Schedule record/manual record/MD record/Alarm record
Playback Mode
Instant playback, normal playback, event playback, mark playback,
smart playback
Record
Playback
Max 4-channel
playback
Max 8-channel
playback
Max 16-channel
playback
Backup Mode
HDD, burner, USB device, network backup
Alarm
Alarm Input
N/A
Alarm Output
N/A
HDD
HDD Port
1 SATA port,does not support eSATA port
One HDD Space
6T
Communication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
1 RJ45 port,
1000Mbps
Ethernet port
Communication
RS485 port
USB
2 USB2.0 ports(One at the front panel and
one at the rear panel)
1 USB2.0 port and
1 USB3.0 port
(One USB2.0 port
at the front panel
and one USB3.0
port at the rear
panel)
Others
Power
DC12V
Power
Consumption
(No HDD)
≤7W
≤8W
≤10W
Working
Temperature
-10℃～＋55℃
Working
Humidity
10%~90%
Dimensions
Compact 1U case, 260mm（W）×220mm（D）×44mm（H）
Weight (No
HDD)
≤0.85KG
≤0.95KG
≤1.05KG
Installation
Mode
Desk
1.3.66 XVR7104HS Series

Dahua XVR5108HS Specifications

General

Video Compression	H.265+/H.265/H.264+/H.264
Video Output	1 HDMI, 1 VGA
USB Interface	2 USB 2.0
Power Supply	12V DC/2A
Video Channels	8 channels
HDD Capacity	Up to 6TB
Operating Temperature	-10°C to +55°C (+14°F to +131°F)
Audio Input/Output	1/1 RCA
Internal HDD	1 SATA interface, up to 6TB
Max IP Camera Input	12 channels
Recording Resolution	1080P/720P
HDMI Output	1
VGA Output	1
Operating Humidity	10%–90% (RH), non-condensing
IP Video Input	8+4 channels
