Page #357 background imageLoading...
Page #357 background image
341
In Figure 4- 56, input tour value and then click to call a tour. Click again
to stop call.
Call Scan
In Figure 4- 56, input Scan value and then click to call a tour. Click again
to stop call.
Rotate
In Figure 4- 56, click to enable the camera to rotate.
System supports preset, tour, pattern, scan, rotate, light and etc function.
Note
Preset, tour and pattern all need the value to be the control parameters. You can
define it as you require.
You need to refer to your camera users manual for Aux definition. In some cases, it
can be used for special process.
Aux
Click , system goes to the following interface. The options here are defined by the
protocol. The aux number is corresponding to the aux on-off button of the decoder. See
Figure 4- 62.
Figure 4- 62
4.3.4 Auto Focus
Note
This function is for the motorized-lens network camera.
For HD auto focus camera, you can go to the PTZ control interface to set. Please
refer to Chapter 4.3.3 PTZ.
On the preview interface, right click mouse and then select Auto focus, you can go to the
following interface. See Figure 4- 63.
