457
Figure 4- 196
4.9.5 System
4.9.5.1 General
4.9.5.1.1Device
General setting includes the following items. See Figure 4- 197.

Device ID: Please input a corresponding device name here.

Device No: Here you can set device number.

Language: System supports various languages: Chinese (simplified), Chinese
(Traditional), English, Italian, Japanese, French, Spanish (All languages listed here
are optional. Slight difference maybe found in various series.)

Video standard: There are two formats: NTSC and PAL.

Instant playback: It is to set playback time you can view in the preview interface. The
value ranges from 5 to 60 minutes.

Auto logout: Here is for you to set auto logout interval once login user remains
inactive for a specified time. Value ranges from 0 to 60 minutes.

Monitor channels when logout: Here you can set channels you want to view when
your account has logged out. Click the button and then cancel the channel name box,
you need to login to view the corresponding video. The channel window displays
in preview interface.

IPC Time Sync: You can input an interval here to synchronize the DVR time and IPC
time.

Dahua XVR5108HS Specifications

General

Video Compression	H.265+/H.265/H.264+/H.264
Video Output	1 HDMI, 1 VGA
USB Interface	2 USB 2.0
Power Supply	12V DC/2A
Video Channels	8 channels
HDD Capacity	Up to 6TB
Operating Temperature	-10°C to +55°C (+14°F to +131°F)
Audio Input/Output	1/1 RCA
Internal HDD	1 SATA interface, up to 6TB
Max IP Camera Input	12 channels
Recording Resolution	1080P/720P
HDMI Output	1
VGA Output	1
Operating Humidity	10%–90% (RH), non-condensing
IP Video Input	8+4 channels
