Dahua XVR5108HS User Manual

602
Figure 5- 153
5.12.1 Search Record
Please set record type, record date, window display mode and channel name.

Select Date
You can click the date on the right pane to select the date. The green highlighted date is
system current date and the blue highlighted date means it has record files.

Window Split
Select window split mode. Click to display in full screen. Click ESC button to exit.
See Figure 5- 154.
Figure 5- 154

Customized playback
Click , you can see the following interface. See Figure 5- 155.

Dahua XVR5108HS Specifications

General

Video Compression	H.265+/H.265/H.264+/H.264
Video Output	1 HDMI, 1 VGA
USB Interface	2 USB 2.0
Power Supply	12V DC/2A
Video Channels	8 channels
HDD Capacity	Up to 6TB
Operating Temperature	-10°C to +55°C (+14°F to +131°F)
Audio Input/Output	1/1 RCA
Internal HDD	1 SATA interface, up to 6TB
Max IP Camera Input	12 channels
Recording Resolution	1080P/720P
HDMI Output	1
VGA Output	1
Operating Humidity	10%–90% (RH), non-condensing
IP Video Input	8+4 channels
