120
Parameters
XVR7104HS
Communication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
Communication
RS485 port
USB
2 USB2.0 ports(One at the front panel and one at the rear panel)
Others
Power
DC12V
Power
Consumption
(No HDD)
≤8W
Working
Temperature
-10~+55
Working
Humidity
10%~90%
Dimensions
Compact 1U case, 260mmW×220mmD×44mmH
Weight No
HDD
0.85KG
Installation
Mode
Desk
1.3.67 XVR42XXA Series
Model
Parameters
XVR4204A
XVR4208A
XVR4216A
System
Main Processor
High-performance industrial embedded micro controller
OS
Embedded LINUX
Video
Video Encode
Standard
H.264
Encode
Resolution
1080N/720P/
960H/D1/HD1/
2CIF/CIF/
1080N@12f/720P@15f/960H/D1/HD1/2
CIF/CIF
Video Frame
Rate
PAL:1~25f/s; NTSC:1~30f/s
Video Bit Rate
32Kbps4096Kbps
Bit Stream
Type
Video stream/composite stream
Dual-Stream
Support
Audio
Encode
Standard
G.711A, G.711U, PCM
Audio
Sampling Rate
8KHz,16Bit
Audio Bit Rate
64Kbps

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Dahua XVR5108HS and is the answer not in the manual?

Dahua XVR5108HS Specifications

General IconGeneral
Video CompressionH.265+/H.265/H.264+/H.264
Video Output1 HDMI, 1 VGA
USB Interface2 USB 2.0
Power Supply12V DC/2A
Video Channels8 channels
HDD CapacityUp to 6TB
Operating Temperature-10°C to +55°C (+14°F to +131°F)
Audio Input/Output1/1 RCA
Internal HDD1 SATA interface, up to 6TB
Max IP Camera Input12 channels
Recording Resolution1080P/720P
HDMI Output1
VGA Output1
Operating Humidity10%–90% (RH), non-condensing
IP Video Input8+4 channels
