Page #190 background imageLoading...
Page #190 background image
174
Model
Parameters
XVR4204A-S2
XVR4208A-S2
XVR4216A-S2
Alarm Output
3-ch alarm output
HDD
HDD Port
2 SATA ports. Does not support eSATA port.
Space/HDD
8T
Communication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
RS485
Communication
1 RS485 port
USB
2 USB2.0 ports(One at the front panel and one at the rear panel)
Other
Power
DC12V
Power
Consumption
No HDD
≤7W
≤8W
≤10W
Working
Temperature
-10℃~+55
Working
Humidity
10%~90%
Dimension
1U case,375mmW×280mmD×50mmH
Weight
No HDD
1.5KG
1.65KG
1.8KG
Installation
Mode
Desk installation
1.3.93 XVR42XXAN-S2 Series
Model
Parameters
XVR4216AN-S2
System
Main Processor
High-performance industrial embedded micro controller
OS
Embedded LINUX
Video
Video Encode
Standard
H.264
Encode
Resolution
1080N@12fps/720P@15fps/960H/D1/HD1/2CIF/CIF
Video Frame
Rate
PAL:1~25f/s; NTSC:1~30f/s
Video Bit Rate
32Kbps4096Kbps
Bit Stream
Type
Video stream/composite stream
Dual-Stream
Support
Audio
Encode
Standard
G.711A, G.711U, PCM, AAC (AAC for the first channel only)
Audio
Sampling Rate
8KHz,16Bit
Audio Bit Rate
64Kbps
