System only backup files with a √ before channel name. You can use Fn or cancel
button to delete √ after file serial number.
Click Start button, system begins copy. At the same time, the backup button becomes
stop button. You can view the remaining time and process bar at the left bottom. See
Figure 4- 81.
Figure 4- 81
When the system completes backup, you can see a dialogue box prompting
successful backup.

File format: Click the file format; you can see there are two options: DAV/ASF.
The file name format usually is: Channel number+Record type+Time. In the file name,
the YDM format is Y+M+D+H+M+S. File extension name is .dav.
Tips:
During backup process, you can click ESC to exit current interface for other operation.
The system will not terminate backup process.
Note
When you click stop button during the burning process, the stop function becomes
activated immediately. For example, if there are ten files, when you click stop system
just backup five files, system only save the previous 5 files in the device (But you can
view ten file names).
4.7.4 Shut Down
In Figure 4- 70, select Shut Down, you can go to the following interface. See Figure 4- 82.
There are three options: Shutdown/logout/reboot.

Dahua XVR5108HS Specifications

General

Video Compression	H.265+/H.265/H.264+/H.264
Video Output	1 HDMI, 1 VGA
USB Interface	2 USB 2.0
Power Supply	12V DC/2A
Video Channels	8 channels
HDD Capacity	Up to 6TB
Operating Temperature	-10°C to +55°C (+14°F to +131°F)
Audio Input/Output	1/1 RCA
Internal HDD	1 SATA interface, up to 6TB
Max IP Camera Input	12 channels
Recording Resolution	1080P/720P
HDMI Output	1
VGA Output	1
Operating Humidity	10%–90% (RH), non-condensing
IP Video Input	8+4 channels
Multi-channel Playback	Up to 8 channels
