56
Parameters
HCVR7104HS3
HCVR7108H-S3
HCVR7116H-S3
one at the rear panel)
USB3.0 port at the
rear panel
and one USB3.0
port at the rear
panel
Others
Power
DC12V
Power
Consumption
≤8W
≤10W
≤15W
Working
Temperature
-10℃～＋55℃
Working
Humidity
10%~90%
Dimensions
Mini 1U case,325mm（W）×245mm（D）×45mm（H）
Weight
≤1.1KG
≤1.25KG
≤1.45KG
Installation
Mode
Desk
1.3.30 HCVR41XXHS-S2 Series
Parameters
HCVR4104HS-S2
HCVR4108HS-S2
HCVR4116HS-S2
System
Main Processor
Industrial embedded micro controller
OS
Embedded LINUX
Video
Parameters
Video Encode
Standard
H.264
Encode
Resolution
720P/960H/D1/HD1/
2CIF/CIF/QCIF
720P(1-15f/s)/960H/D1/HD1/
2CIF/CIF/QCIF
Video Frame
Rate
HDCVI:1～25f/s（PAL）;
1~30f/s（NTSC）
CVBS:1~25f/s（PAL）;
1~30f/s（NTSC）
HDCVI:1 ～ 15f/s (The 1
st
channel
supports 25/30fps/)
CVBS:1~25f/s（PAL）; 1~30f/s（NTSC）
Video Bit Rate
2048Kbps-4096Kbps,
For 720P: default setup
is 2Mbps,max supports
4Mbps.
For 960H: default
setup is 1Mbps,max
supports 3Mbps.
1024Kbps-4096Kbps,
For 720P: default setup is 1Mbps,max
supports 4Mbps.
For 960H: default setup is 1Mbps,max
supports 3Mbps.
Bit Stream Type
Video stream/composite stream
Dual-Stream
Support
Audio
Parameters
Encode
Standard
G.711A/G.711U/PCM
Audio Sampling
Rate
8KHz,16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
4-channel,BNC port
8-channel,BNC port
16-channel,

Dahua XVR5108HS Specifications

General

Video Compression	H.265+/H.265/H.264+/H.264
Video Output	1 HDMI, 1 VGA
USB Interface	2 USB 2.0
Power Supply	12V DC/2A
Video Channels	8 channels
HDD Capacity	Up to 6TB
Operating Temperature	-10°C to +55°C (+14°F to +131°F)
Audio Input/Output	1/1 RCA
Internal HDD	1 SATA interface, up to 6TB
Max IP Camera Input	12 channels
Recording Resolution	1080P/720P
HDMI Output	1
VGA Output	1
Operating Humidity	10%–90% (RH), non-condensing
IP Video Input	8+4 channels
