68
Model
Parameters
HCVR7204A-V2
HCVR7208A-V2
Working Humidity
10%~90%
Dimension
1U case,375mmW×280mmD×50mmH
Weight
1.5kg2.5kgexclude HDD
Installation Mode
Desk installation
1.3.38 HCVR42XXA-S2/4216AN-S2 Series
Model
Parameters
HCVR4204A-
S2
HCVR4208A-
S2
HCVR4216A-
S2
HCVR4216AN
-S2
System
Main Processor
High-performance industrial embedded micro controller
OS
Embedded LINUX
Video
Video Encode
Standard
H.264
Encode
Resolution
720P(1-15fps)/960H/D1/HD1/2CIF/CIF/QCIF (for sub-stream only)
Video Frame
Rate
HDCVI:115f/sThe 1
st
channel supports 25/30f/s
CVBS:1~25f/sPAL; 1~30f/sNTSC
Video Bit Rate
1024Kbps-4096Kbps,
For 720P:default value is 1Mbps,max value is 4Mbps
For 960H:default value is 1Mbps,max value is 3Mbps
Bit Stream
Type
Video stream/composite stream
Dual-Stream
Support
Audio
Encode
Standard
G.711A, G.711U, PCM
Audio
Sampling Rate
8KHz,16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
4-ch, BNC port
8-ch, BNC port
16-ch, BNC
port
16-ch, BNC
port
Network Video
Input
Max 2 IPC connections8Mbps
Video Output
1-ch VGA output,
1-ch HDMI output,
HDMI/ VGA video output at the same time (VGA/HDMI of the same
video source)
Loop Output
N/A
Matrix Output
N/A
Audio Port
Audio Input
4-ch,RCA port,
1-ch,RC
A port
Audio Output
1-ch,RCA port
Bidirectional
Talk Input
SupportReuse the audio port
