238
SN
Icon
Name
Note
12
USB2.0 port
USB2.0 port. Connect to mouse, USB storage
device, USB burner and etc.
2.2.28 HCVR52XXA-S2/ HCVR5216AN-S2 Series
This HCVR5204A-S2 products’ rear panel is shown as below. See Figure 2- 68.
Figure 2- 68
This HCVR5208A-S2 products’ rear panel is shown as below. See Figure 2- 69.
Figure 2- 69
This HCVR5216A-S2 products’ rear panel is shown as below. See Figure 2- 70.
Figure 2- 70
This HCVR5216AN-S2 products’ rear panel is shown as below. See Figure 2- 71.
Figure 2- 71
