Dahua XVR5108HS User Manual

294
Figure 4- 2
Step 4 Set unlock pattern.
After set unlock pattern, device goes to password protection interface. See
Figure 4- 3.
Note

The unlock pattern shall at least contain 4 grids.

Device adopts unlock pattern to login by default if you have set pattern here.
If there is no unlock pattern, please input the password to login.

Click Skip if there is no need to set unlock pattern.
Figure 4- 3

Dahua XVR5108HS Specifications

General

Video Compression	H.265+/H.265/H.264+/H.264
Video Output	1 HDMI, 1 VGA
USB Interface	2 USB 2.0
Power Supply	12V DC/2A
Video Channels	8 channels
HDD Capacity	Up to 6TB
Operating Temperature	-10°C to +55°C (+14°F to +131°F)
Audio Input/Output	1/1 RCA
Internal HDD	1 SATA interface, up to 6TB
Max IP Camera Input	12 channels
Recording Resolution	1080P/720P
HDMI Output	1
VGA Output	1
Operating Humidity	10%–90% (RH), non-condensing
IP Video Input	8+4 channels
