Dahua XVR5108HS User Manual

306
Note
Click Add more to add more holidays if necessary.
Step 4 Click Add button.
Device goes back to Figure 4- 16 to display the new holiday.
Note

The new holiday state is on by default. Select from the dropdown list to
disable.

Drag the slide bar, click to edit holiday, click to delete holiday.
Note
After successfully set holiday here, you can view holiday item in Schedule interface. It
is for you to set holiday schedule record/snapshot settings.
4.1.4.2 Network
Before the operation, make sure the device has properly connected the network cable.
Besides startup wizard and configuration wizard, from main
menu->Setting->Network->TCP/IP, you can also go to the network interface.
Step 1 From main menu->Setting->Network->TCP/IP.
Enter TCP/IP interface. See Figure 4- 18.
Step 2 Set parameters.

Network Mode: Includes multiple access, fault tolerance, and load balancing. Please
note the network mode is not for product of single-Ethernet card.

Multiple-address mode: eth0 and eth1 operate separately. You can use the
services such as HTTP, RTP service via etho0 or the eth1. Usually you need to
set one default card (default setup is etho) to request the auto network service
form the device-end such as DHCP, email, FTP and etc. In multiple-address
mode, system network status is shown as offline once one card is offline.

Network fault-tolerance: In this mode, device uses bond0 to communicate with
the external devices. You can focus on one host IP address. At the same time,
you need to set one master card. Usually there is only one running card (master
card).System can enable alternate card when the master card is malfunction. The
system is shown as offline once these two cards are both offline. Please note
these two cards shall be in the same LAN.

Load balance: In this mode, device uses bond0 to communicate with the external
device. The eth0 and eth1 are both working now and bearing the network load.
Their network load are general the same. The system is shown as offline once
these two cards are both offline. Please note these two cards shall be in the same
LAN.
 Default Network Card: Please select eth0/eth1/bond0(optional) after enable
multiple-access function
 Main Network Card: Please select eth0/eth1 (optional).after enable multiple

Dahua XVR5108HS Specifications

General

Video Compression	H.265+/H.265/H.264+/H.264
Video Output	1 HDMI, 1 VGA
USB Interface	2 USB 2.0
Power Supply	12V DC/2A
Video Channels	8 channels
HDD Capacity	Up to 6TB
Operating Temperature	-10°C to +55°C (+14°F to +131°F)
Audio Input/Output	1/1 RCA
Internal HDD	1 SATA interface, up to 6TB
Max IP Camera Input	12 channels
Recording Resolution	1080P/720P
HDMI Output	1
VGA Output	1
Operating Humidity	10%–90% (RH), non-condensing
IP Video Input	8+4 channels
Multi-channel Playback	Up to 8 channels
