448
Figure 4- 184
4.9.4.4 Advanced
It is to set HDD group, and HDD group setup for main stream, sub stream and snapshot
operation
4.9.4.4.1HDD
CAUTION
HDD group and quota mode cannot be valid at the same time. System needs to restart
once you change the mode here.
Step 1 From main menu->Setting->Storage->Advanced->HDD.
Enter HDD interface. See Figure 4- 185.
Step 2 Set parameters.
HDD: Here you can view the HDD amount the device can support.
Group: It lists the HDD Group number of current hard disk.
