Dahua XVR5108HS User Manual

527
5- 53.
You can see HTTPS default value is 443.
Figure 5- 53
5.10.2.3.4 Login
Open the browser and then input https://xx.xx.xx.xx:port.
xx.xx.xx.xx: is your device IP or domain mane.
Port is your HTTPS port. If you are using default HTTPS value 443, you do not need to
add port information here. You can input https://xx.xx.xx.xx to access.
Now you can see the login interface if your setup is right.
5.10.2.4 WIFI
Note
This function is for some series products only.
This function allows you to connect the DVR to the network via the WIFI.
Step 1 From main window->Setup->Network->WIFI.
Enter WIFI interface. See Figure 5- 54.
Figure 5- 54
Step 2 Check the box to enable WIFI function and then click the Search SSID button. It
is to view all the wireless network information in the following list.

Dahua XVR5108HS Specifications

General

Video Compression	H.265+/H.265/H.264+/H.264
Video Output	1 HDMI, 1 VGA
USB Interface	2 USB 2.0
Power Supply	12V DC/2A
Video Channels	8 channels
HDD Capacity	Up to 6TB
Operating Temperature	-10°C to +55°C (+14°F to +131°F)
Audio Input/Output	1/1 RCA
Internal HDD	1 SATA interface, up to 6TB
Max IP Camera Input	12 channels
Recording Resolution	1080P/720P
HDMI Output	1
VGA Output	1
Operating Humidity	10%–90% (RH), non-condensing
IP Video Input	8+4 channels
