Dahua XVR5108HS User Manual

582
Select a channel group and then click ,you can delete it.
Modify channel group
Select a channel group and then double click, you can see the following interface. See
Figure 5-122. You can change the setup and then click OK button.
Figure 5- 122
Adjust channel group sequence.
Click or to change channel sequence.
5.10.5.4 RS232
Note
This function is for some series product only.
The RS232 interface is shown as in Figure 5- 123.
Figure 5- 123
Please refer to the following sheet for detailed information.
Parameter
Function
Protocol
Select the corresponding dome protocol.
Default setup is console.
Baud Rate
Select the baud rate.
Default setup is 115200.
Data Bit
The value ranges from 5 to 8.
Default setup is 8.

Dahua XVR5108HS Specifications

General

Video Compression	H.265+/H.265/H.264+/H.264
Video Output	1 HDMI, 1 VGA
USB Interface	2 USB 2.0
Power Supply	12V DC/2A
Video Channels	8 channels
HDD Capacity	Up to 6TB
Operating Temperature	-10°C to +55°C (+14°F to +131°F)
Audio Input/Output	1/1 RCA
Internal HDD	1 SATA interface, up to 6TB
Max IP Camera Input	12 channels
Recording Resolution	1080P/720P
HDMI Output	1
VGA Output	1
Operating Humidity	10%–90% (RH), non-condensing
IP Video Input	8+4 channels
