Dahua XVR5108HS User Manual

597
Please refer to the following sheet for detailed information.
Parameter
Function
Import
It is to import the local setup files to the system.
Export
It is to export the corresponding WEB setup to your local PC.
5.10.5.12 Default
Note
This function is for admin user only.
The default setup interface is shown as in Figure 5- 146.
Here you can select Channel/Network/Event/Storage/System. Or you can check the All
box to select all items.
Figure 5- 146
5.10.5.13 Upgrade
CAUTION
 During the upgrade process, do not unplug the power cable, network cable, or
shutdown the device.
 Improper upgrade program may result in device malfunction!
There are two upgrade modes: file upgrade and online upgrade.
5.10.5.13.1.1 File Upgrade
The upgrade interface is shown as in Figure 5- 147.
Please select the upgrade file and then click the update button to begin update. Please
note the file name shall be as *.bin.
Figure 5- 147

Dahua XVR5108HS Specifications

General

Video Compression	H.265+/H.265/H.264+/H.264
Video Output	1 HDMI, 1 VGA
USB Interface	2 USB 2.0
Power Supply	12V DC/2A
Video Channels	8 channels
HDD Capacity	Up to 6TB
Operating Temperature	-10°C to +55°C (+14°F to +131°F)
Audio Input/Output	1/1 RCA
Internal HDD	1 SATA interface, up to 6TB
Max IP Camera Input	12 channels
Recording Resolution	1080P/720P
HDMI Output	1
VGA Output	1
Operating Humidity	10%–90% (RH), non-condensing
IP Video Input	8+4 channels
