Model
Parameters
HCVR5204A-V2
HCVR5208A-V2
HCVR5216A-V2
Encode Resolution
720P/960H/D1/HD1/2CIF/CIF/QCIF (for sub-stream only)
Video Frame Rate
PAL:1~25f/s; NTSC:1~30f/s
Video Bit Rate
1536Kbps-4096Kbps,
For 720P:default value is 2Mbps,max value is 4Mbps
Bit Stream Type
Video stream/composite stream
Dual-Stream
Support
Audio
Encode Standard
G.711A, G.711U, PCM
Audio Sampling Rate
8KHz,16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video Input
4-ch, BNC port
8-ch, BNC port
16-ch, BNC port
Network Video Input
Switch 2 analog channels to the IP channels（8Mbps）
Video Output
1-ch VGA output,
1-ch HDMI output,
HDMI/ VGA video output at the same time (VGA/HDMI of the
same video source)
Loop Output
N/A
Matrix Output
N/A
Audio Port
Audio Input
4-ch,RCA port, audio via coaxial cable
Audio Output
1-ch,RCA port
Bidirectional Talk
Input
Support（Reuse the audio port）
Record
Record Mode
Auto record, manual record, motion detect record, alarm
record
Record Playback
Max 4-ch playback
Max 8-ch
playback
Max 16-ch
playback
Backup Mode
HDD, burner, flash disk, network backup.
Alarm
Alarm Input
4-ch alarm input
8-ch alarm input
16-ch alarm input
Alarm Output
3-ch alarm output
HDD
HDD Port
2 SATA ports. Does not support eSATA port
Space/HDD
4T
Communication
Port
Network
1 RJ45 port, 1000Mbps Ethernet port
Communication
RS485 port
USB
2 USB ports
Other
Power
DC12V
Power Consumption
≤30W（exclude HDD）
Working Temperature
-10℃～＋55℃
Working Humidity
10%~90%
Dimension
1U case,375mm（W）×280mm（D）×50mm（H）
Weight
1.5kg～2.5kg（exclude HDD）
Installation Mode
Desk installation

Dahua XVR5108HS Specifications

General

Video Compression	H.265+/H.265/H.264+/H.264
Video Output	1 HDMI, 1 VGA
USB Interface	2 USB 2.0
Power Supply	12V DC/2A
Video Channels	8 channels
HDD Capacity	Up to 6TB
Operating Temperature	-10°C to +55°C (+14°F to +131°F)
Audio Input/Output	1/1 RCA
Internal HDD	1 SATA interface, up to 6TB
Max IP Camera Input	12 channels
Recording Resolution	1080P/720P
HDMI Output	1
VGA Output	1
Operating Humidity	10%–90% (RH), non-condensing
IP Video Input	8+4 channels
