9
• Control systems
• Individual control systems • ARC*/BRC*
BRC7E530W - Infrared remote control
Dimensional drawing
BRC7E63W - Infrared remote control
Dimensional drawing
(Unit: mm)
(Unit: mm)
3D038937A
3D028963B
Remote control dimensions
Remote control dimensions
Receiver installation procedure
Receiver installation procedure
Transmitting part
Transmitting part
Receiver detail
Receiver detail
Decoration panel
Receiver
Receiver
Drain piping side Refrigerantpipingside
(BYFQ60BW1)
(BYFQ60B7W1)
(BYFQ60B8W1)
Remote control holder
installation procedure
(installationtowallsurface)
Remote control holder
installation procedure
(installationtowallsurface)
Liquid crystal
remote control
Liquidcrystalinfrared
remote control
(wireless)
Remote
control holder
Remote control
holder
(wireless)
