Daikin FT25DVM Service Manual

Si01-501 FT09/13DV2S, FT25/35DVM, FT25/35DSG
Removal Procedure 155
Step Procedure Points
3. Removing the vertical
blade
1
2
Unfasten the hooks at
the shaft mounting part
by pressing them with a
flat screwdriver.
Unfasten the hooks at
the upper 2 positions.
3
Remove the vertical
blade toward yourself.

Six vertical blades are
united as a set.
(It is impossible to replace
only one blade.)

The set of blades is not
marked for difference
between right and left.

Daikin FT25DVM Specifications

General

Brand	Daikin
Model	FT25DVM
Category	Air Conditioner
Language	English
