Printed Circuit Board Connector Wiring Diagram Si01-501
18 Printed Circuit Board Connector Wiring Diagram
1.2 Outdoor Unit
1.2.1 R60DSG
Connectors PCB (1)(Control PCB)
PCB (2)(Power Supply PCB)
PCB (3)(Service Monitor PCB)
MID
SPM
Note: Other Designations
PCB (1)(Control PCB)
PCB (2)(Power Supply PCB)
PCB (3)(Service Monitor PCB)
MID
1) S10, AC2 Connector for terminal strip
2) S20 Connector for electronic expansion valve coil
3) S31, S32 Connector for SPM
4) S33, S71 Connector for MID
5) S40 Connector for overload protector
6) S51, S101 Connector for service monitor PCB
7) S90 Connector for thermistors
(outdoor air, heat exchanger, and discharge pipe)
8) S91 Connector for fin thermistor
9) AC1, E Connector for power supply PCB
10) H1, H2 Connector for diode bridge
1) HL Connector for terminal strip
2) HAC1, HE1 Connector for control PCB
3) HE2 Connector for earth
1) S52, S102 Connector for control PCB
1) S34, S72 Connector for control PCB
2) S70 Connector for fan motor
1) CN11, CN14 Connector for control PCB
2) L1, L2 Connector for reactor
1) FU2 Fuse (3.15A)
1) FU1 Fuse (30A)
2) V3 Varistor
1) LED A Service monitor LED
2) SW1 Forced operation ON/OFF switch
1) FU201 Fuse (3.15A)
