Daikin FT25DVM Service Manual

Specifications Si01-501
6 Specifications
1. Specifications
50Hz 220V
Note:

MAX. interunit piping length: 25m

MAX. interunit height difference: 15m

Amount of additional charge of refrigerant 20g/m for piping length exceeding 10m

The data are based on the conditions shown in the table below.
Models
Indoor Units FT09DV2S FT13DV2S
Outdoor Units R09DV2S R13DV2S
Capacity (Rated)
kW 2.6 3.70
Btu/h 8,900 12,700
kcal/h 2,240 3,200
Moisture Removal L/h 1.2 1.9
Running Current (Rated) A 3.94 5.17
Power Consumption (Rated) W 810 1,105
Power Factor % 93.4 97.2
COP (Rated) W/W 3.21 3.35
Piping
Connections
Liquid mm φ 6.4 φ 6.4
Gas mm φ12.7 φ12.7
Drain mm φ18.0 φ18.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Indoor Units FT09DV2S FT13DV2S
Front Panel Color White White
Air Flow Rate
m³/min
(cfm)
H 8.8(311) 11(388)
M 7.4(261) 8.9(314)
L 5.9(208) 6.8(240)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 18 40
Speed Steps 5 Steps, Auto 5 Steps, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable/Washable/Mildew Proof Removable/Washable/Mildew Proof
Running Current A 0.17 0.19
Power Consumption W 35 40
Power Factor % 93.6 95.7
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 283×800×195 283×800×195
Packaged Dimensions (H×W×D) mm 265×855×340 265×855×340
Weight kg 9 9
Gross Weight kg 12 12
Operation
Sound
H/L dBA 36/28 42/31
Outdoor Units R09DV2S R13DV2S
Casing Color Ivory White Ivory White
Compressor
Type Hermetically Sealed Rotary Type Hermetically Sealed Rotary Type
Model RC30BV1R2T RH207VHST
Motor Output W 700 1,000
Refrigerant
Oil
Type SUNISO 4GSD. I. DIAMOND MS56
Charge L 0.4 0.52
Refrigerant
Type R22 R22
Charge kg 1.25 1.15
Air Flow Rate
m³/min 28 28
cfm 986 988
Fan
Type Propeller Propeller
Motor Output W 27 27
Running Current (Rated) A 3.77 4.98
Power Consumption (Rated) W 775 1,065
Power Factor % 93.4 97.2
Starting Current A 20 23
Dimensions (H×W×D) mm 540×750×270 540×750×270
Packaged Dimensions (H×W×D) mm 609×940×360 609×940×360
Weight kg 33 38
Gross Weight kg 37 42
Operation Sound dBA 48 48
Drawing No. 3D048874 3D049255
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB/24°CWB
7.5m
