Si01-501 Instructions
System Configuration 89
19
1. Open the front panel. (page 18.)
2. Pull out the air filters.
•
Push a little upwards the tab at the center of
each air filter, then pull it down.
3. Take off the air purifying filter
with photocatalytic deodorizing function.
• Raise the lower side of the air purifying filter with
photocatalytic deodorizing function and remove it
from the tabs (3 at top and 3 at bottom).
4. Clean or replace each filter.
See below.
5.
Set the air filter, air purifying filter with photocatalytic deodoriz-
ing function as they were and close the front panel.
•
Press the top of the air purifying filter with photocatalytic deodorizing
function onto the tabs (3 at top). Then press the bottom of the filter
up slightly, and press it onto the tabs (3 at bottom).
•
Press the front panel at both sides and the center.
Air Filter
1.
Wash the air filters with water or clean them with vacuum cleaner.
•
If the dust does not come off easily, wash them with neutral detergent
thinned with lukewarm water, then dry them up in the shade.
•
It is recommended to clean the air filters every two weeks.
Air purifying filter with photocatalytic deodorizing function. (gray)
The air purifying capacity of the air purifying filter with photocatalytic deodorizing function can be
renewed by washing it with water once every 6 months. We recommend replacing it once every 3 years.
[ Maintenance ]
1. Remove dust with a vacuum cleaner and wash lightly with water.
2.
If it is very dirty, soak it for 10 to 15 minutes in water mixed with a neutral cleaning detergent.
3. After washing, shake off remaining water and dry in the shade.
4.
Since the material is made out of paper, do not wring out the filter when removing water from it.
[ Replacement]
1. Remove the tabs on the filter frame and replace with a new filter.
• Dispose of the old filter as flammable waste.
Filters
tabs (3 at top)
tabs (3 at bottom)
To Next Page
