Si18-201 Protection Device
Main Functions 107
2. Protection Device
2.1 Outdoor Unit
RMX140JVM
M1C Compressor JT100F-VD 3.3kW × 1 Scroll
J1HC Crankcase Heater —
HPS High Pressure Protection (3SA45022-1)
OFF: 2.94MPa ON: 2.16MPa
SP Low Pressure Sensor (3SA48112-1) PS8040A
0~0.98MPa
Y1E
(EV
G
)
Electronic
Expansion Valve
Main Body (2SB45422-1)
Coil (3SB45348-8)
LAM-B30YHDM-1
Y2E
(EVL
)
Electronic
Expansion Valve
Main Body (2SB45422-1)
Coil (3SB45348-1)
LAM-B30YHDM-1
Y3E
(EV
P
)
Electronic
Expansion Valve
Main Body (3SA52028-1)
Coil (3P002169-1)
EKV-30D36
Y1R 4-Way Valve Main Body (3SA52023-1)
V40100B
Coil (3SA52037-5-KU)
V40100B H/p Only
M1F Fan Motor (Lower) (3SB40509-1) H41, L30-W × 1 8P Propeller
M2F Fan Motor (Upper) (3SB40509-1) H53, L38-W × 1 8P Propeller
C1R Capacitor for Fan Motor (3EB60099-1) 2,500
µ
F
L1R Direct Current Reactor
(3EB75084-1)
L2R Direct Current Reactor (3EB75084-1)
F1U FUSE (3EB82010-1) (250)V (3.15)A
R1T Thermistor (Condenser) (3EB70006-19) R25 = 20k
Ω
B = 3,950
R2T Thermistor (Liquid) (3EB70006-29) R25 = 20k
Ω
B = 3,950
R3T Thermistor (Outdoor) (3EB70001-9) R25 = 20k
Ω
B = 3,950
R4T Thermistor (Suction) (3EB70006-19) R25 = 20k
Ω
B = 3,950
R5T Thermistor (Discharge) (3EB70006-19) R25 = 20k
Ω
B = 3,950
