Printed Circuit Board Connector Wiring Diagram and Name Si18-201
70 Printed Circuit Board Connector Wiring Diagram and Name
1.6 FLK25~60HV Series, FLX25~60HV Series,
FLK50 / 60JV Series, FLX50 / 60JV Series
Cooling Only FLK25 / 35 / 50 / 60HVE (C) (T), FLK25 / 35HVEA, FLK50 / 60JVEA (9)
Heat Pump FLX25 / 35HVEA, FLX25 / 35HV1NB, FLX25 / 35 / 50 / 60HVEC (T),
FLX50 / 60JV1B
Printed Circuit
Board
Printed Circuit Board(1) (Control PCB)
Printed Circuit Board(2) (Power Supply PCB)
Printed Circuit Board(3) (Display PCB)
Printed Circuit Board(4) (Signal Receiver PCB)
Name of Connector
Other Designation
1) S1 Connector for Fan Motor (Power Supply)
2) S6 Connector for Swing Motor
3) S7 Connector for Fan Motor
4) S21 Connector for Centralized Control
5) S24 Connector for PCB3 (to S25)
6) S25 Connector for PCB1 (to S24)
7) S26 Connector for PCB4 (to S27)
8) S27 Connector for PCB1 (to S26)
9) S31 Connector for Thermistor (R1T)
10) S32 Connector for Thermistor (R2T,R3T)
11) S36 Connector for PCB1 (to S37)
12) S37 Connector for PCB2 (to S36)
1) FU Fuse 3.15A
2) S2W Address Switch
3) S7W Operation Switch
4) S8W Cleaning Indicator Reset Switch
5) H1P LED for Filter Sign
6) H2P LED for Timer
7) H3P LED for Operation
8) LED A,B LED for Service Monitor
9) JB Control Function Change Jumper (When cut
Setting of Fan RPM 0
during Thermostat Off)
10) JC Control Function Change Over (When cut
No Auto Restart Function)
