Si18-201 Printed Circuit Board Connector Wiring Diagram and Name
Printed Circuit Board Connector Wiring Diagram and Name 75
1.8 FDYM60FA, FDYM03FA Series
Cooling Only /
Heat Pump
FDYM60FAV1, FDYM60FAV1C, FDYM60FAVAL
FDYM03FAV1, FDYM03FAV1C, FDYM03FAVAL
Name of Connector
Other Designation
1) X5A Connector for Wired Remote Controller
2) X10A Connector for Transformer
3) X11A Connector for Transformer
4) X15A Jumpered
5) X18A Connector for Thermistor (Coil)
6) X19A Connector for Thermistor (Air)
7) X21A Connector for Fan Motor
8) X27A Connector for Outdoor Unit
9) X30A Connector for Interface Adaptor (Option)
10) X33A Connector for Adaptor for Wiring (Option)
11) X35A Connector for Group Control Adaptor (Option)
1) H1P,H2P Service Monitor LED (Green)
To Next Page
