Si18-201 Outdoor Unit
Removal Procedure 331
2.4 Removal of Thermistor
Procedure Warning Be sure to wait 10 minutes or more after turning off all power supplies
before disassembling work.
Step Procedure Points
"
Detach the top, front
panel (2) and side panel,
referring to the
instructions in "Removal
of Outer Panels".
"
Take out the electrical
box.
1
Disconnect the
thermistors from the
holders, and pass them
out of the through
opening of the piping
plate.
2
Undo the two tie-wraps
and disconnect the
suction pipe thermistor.
"
In reconnecting the
suction pipe thermistor,
bend the harness back
into its original route and
apply the tie-wraps.
3
Disconnect the heat
exchanger
intermediate
thermistor.
4
Disconnect the liquid
pipe thermistor.
5
Disconnect the
discharge pipe
thermistor.
"
In reconnecting the
thermistors, be sure to fit
their mounting springs into
position.
To Next Page
