Si18-201 Printed Circuit Board Connector Wiring Diagram and Name
Printed Circuit Board Connector Wiring Diagram and Name 73
1.7 FHYC35~71KV Series
Cooling Only /
Heat Pump
FHYC35 / 50 / 60 / 71KVE9, FHYC35 / 50 / 60 / 71KV1C9
Name of Connector
Other Designation
1) X5A Connector for Wired Remote Controller
2) X10A Connector for Transformer
3) X11A Connector for Transformer
4) X15A Connector for Float Switch
5) X18A Connector for Thermistor (Coil)
6) X19A Connector for Thermistor (Air)
7) X20A Connector for Fan Motor
8) X24A Connector for Wireless Remote Controller (Option)
9) X25A Connector for Drain Pump
10) X27A Connector for Outdoor Unit
11) X30A Connector for Interface Adaptor (Option)
12) X33A Connector for Adaptor for Wiring (Option)
13) X35A Connector for Group Control Adaptor (Option)
14) X36A Connector for Swing Flap Motor
1) SS1 Selector Switch (Emergency)
2) HAP,HBP Service Monitor LED (Green)
