Si18-201 Printed Circuit Board Connector Wiring Diagram and Name
Printed Circuit Board Connector Wiring Diagram and Name 61
1.2 Outdoor Unit RMK (X) 140JVMT (C) 9 (8), RMK140JAVM,
RMX140JVMB, RMK (X) 140JZVMA (B)
Cooling Only RMK140JVMT (C) 9 (8), RMK140JAVM, RMK140JZVMA
Heat Pump RMX140JVMT (C) 9 (8), RMX140JVMB, RMX140JZVMB
Printed Circuit
Board
Printed Circuit Board (1) (Control PCB)
Printed Circuit Board (2) (Filter PCB)
Printed Circuit Board (3) (Fan Control PCB)
Printed Circuit Board (4) (Indicator PCB)
Name of Connector
PCB 1
PCB 2
PCB 3
1) S101 Connector to PCB 3 (to S501)
2) S102 Connector to PCB 3 (to S502)
3) S103 Connector to PCB 2 (to S903)
4) S104 Connector to PCB 2 (to S904)
5) S105 Connector to SP (Low Pressure Sensor)
6) S107 Connector to PCB 2 (to S907)
7) S108 Connector to Y1E EVG (Electronic Expansion Valve)
8) S109 Connector to Y2E EVL (Electronic Expansion Valve)
9) S110 Connector to Y3E EVP (Electronic Expansion Valve)
10) S111 Connector to Y1R (4 Way Valve)
11) S114 Connector to Thermistors
12) S131 Connector to HPS (High Pressure Switch)
13) S132 Connector to PCB 2 (to S908)
14) S140 Connector to Active Module
15) S151 Connector to PCB 2 (to S951)
1) S903 Connector to PCB 1 (to S103)
2) S904 Connector to PCB 1 (to S104)
3) S906 Connector of Communication Wire to Each Indoor Units
4) S907 Connector to PCB 1 (to S107)
5) S908 Connector to PCB 1 (to S132)
6) S951 Connector to PCB 1 (to S151)
7) S952 Connector to Power Supply (N, L)
1) S501 Connector to PCB 1 (to S101)
2) S502 Connector to PCB 1 (to S102)
3) S504 Connector to FAN M1F
4) S506 Connector to FAN M2F
5) S514 Connector to FAN M1F
6) S516 Connector to FAN M2F
7) S517 Connector to C1R (Capacitor)
To Next Page
