Si18-201 Specifications
Specifications 57
"
Floor Standing Type
★
Refer to Engineering Data Book.
"
2.5kW Class · 3.5kW Class
50Hz 230V
Model
FVX25KZV1B FVX35KZV1B
Cooling Heating Cooling Heating
Rating Capacity kW 2.5 3.4 3.5 4.2
Front Panel Color Almond White
Air Flow Rates
m³/min
H 8.1 9.2 8.3 9.2
M 6.2 7.0 6.3 7.1
L 4.3 4.8 4.3 5.0
cfm
H 286 325 293 325
M 219 247 222 251
L 152 169 152 177
Fan
Type Cross Flow Fan
Motor Output W 14
Speed Steps 5 Steps and Auto
Air Filter Removable / Washable / Mildew Proof
Running Current
★
(Rated) A 0.14 0.15
Power Consumption
★
(Rated) W 32 34
Power Factor
★
% 99.4 98.6
Temperature Control Microcomputer Control
Dimensions (H×W×D) mm 600×650×195
Package Dimensions (W×D×H) mm 764×288×702
Weight kg 13
Gross Weight kg 18
Operation Sound dBA
H38383939
M32323333
L26262626
Heat Insulation Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
Gas mm
φ
9.5
φ
12.7
Drain mm
φ
20.0
Drawing No. 3D029440 3D029441
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
