Specifications Si18-201
56 Specifications
"
Floor / Ceiling Suspended Dual Type
★
Refer to Engineering Data Book.
"
2.5kW Class · 3.5kW Class
50Hz 230V
Model
FLX25HV1NB FLX35HV1NB
Cooling Heating Cooling Heating
Rating Capacity kW 2.5 3.86 3.5 4.42
Front Panel Color Almond White
Air Flow Rates
m³/min
H 7.6 9.2 8.7 10.0
M 6.8 8.3 7.7 9.0
L 6.0 7.4 6.6 8.0
cfm
H 268 325 307 353
M 240 293 270 318
L 212 261 233 282
Fan
Type Sirocco Fan
Motor Output W 34
Speed Steps 5 Steps and Auto
Air Filter Removable / Washable / Mildew Proof
Running Current
★
(Rated) A 0.32 0.34 0.36
Power Consumption
★
(Rated) W 70 74 78 78
Power Factor
★
% 95.1 94.6 94.2 94.2
Temperature Control Microcomputer Control
Dimensions (H×W×D) mm 490×1,050×200
Package Dimensions (W×D×H) mm 1,100×566×284
Weight kg 16
Gross Weight kg 22
Operation Sound dBA
H37373839
M34343536
L31313233
Heat Insulation Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
12.7
Drain mm
φ
18.0
φ
18.0
"
5.0kW Class · 6.0kW Class
50Hz 230V
Model
FLX50JV1B FLX60JV1B
Cooling Heating Cooling Heating
Rating Capacity kW 5.0 6.1 5.7 6.7
Front Panel Color Almond White
Air Flow Rates
m³/min
H 11.4 12.1 12.0 12.8
M 9.9 9.8 10.6 10.6
L 8.5 7.5 9.3 8.4
cfm
H 402 427 424 452
M 349 346 374 374
L 300 265 328 297
Fan
Type Sirocco Fan
Motor Output W 34
Speed Steps 5 Steps and Auto
Air Filter Removable / Washable / Mildew Proof
Running Current
★
(Rated) A 0.43 0.42 0.45 0.43
Power Consumption
★
(Rated) W 96 96 98 96
Power Factor
★
% 97.1 99.4 94.7 97.1
Temperature Control Microcomputer Control
Dimensions (H×W×D) mm 490×1,050×200
Package Dimensions (W×D×H) mm 1,100×566×284
Weight kg 17
Gross Weight kg 24
Operation Sound dBA
H47464847
M43414542
L39354137
Heat Insulation Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
12.7
φ
15.9
Drain mm
φ
18.0
φ
18.0
Drawing No. 3D029186 3D029187
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
