Specifications Si18-201
52 Specifications
1.6 Indoor Units (for Europe)
1.6.1 Heat Pump
"
Wall Mounted Type
★
Refer to Engineering Data Book.
"
2.5kW Class · 3.5kW Class
50Hz 230V
Model
FTX25JAV1NB FTX35JAV1NB
Cooling Heating Cooling Heating
Rating Capacity kW 2.5 3.4 3.5 4.2
Front Panel Color Almond White
Air Flow Rates
m³/min
H 7.1 8.4 7.4 8.4
M 5.9 7.0 6.0 7.1
L 4.6 5.7 4.7 5.9
cfm
H 251 297 261 297
M 208 247 212 251
L 162 201 166 208
Fan
Type Cross Flow Fan
Motor Output W 18
Speed Steps 5 Steps and Auto
Air Filter Removable / Washable / Mildew Proof
Running Current
★
(Rated) A 0.18
Power Consumption
★
(Rated) W 40
Power Factor
★
% 96.6
Temperature Control Microcomputer Control
Dimensions (H×W×D) mm 273×784×185
Package Dimensions (W×D×H) mm 834×325×258
Weight kg 7.5
Gross Weight kg 11
Operation Sound dBA
H38383939
M32323333
L26262727
Heat Insulation Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
Gas mm
φ
9.5
φ
12.7
Drain mm
φ
18.0
Drawing No. 3D027497B 3D027498B
50Hz 230V
Model
FTXD25KZV1B FTXD35KZV1B
Cooling Heating Cooling Heating
Rating Capacity kW 2.5 3.4 3.5 4.2
Front Panel Color Almond White
Air Flow Rates
m³/min
H 7.5 8.0 7.9 8.0
M 5.8 6.4 6.1 6.5
L 4.0 4.8 4.3 5.0
cfm
H 265 282 279 282
M 203 226 215 229
L 141 169 152 177
Fan
Type Cross Flow Fan
Motor Output W 18
Speed Steps 5 Steps and Auto
Air Filter Removable / Washable / Mildew Proof
Running Current
★
(Rated) A 0.18
Power Consumption
★
(Rated) W 40
Power Factor
★
% 96.6
Temperature Control Microcomputer Control
Dimensions (H×W×D) mm 273×784×185
Package Dimensions (W×D×H) mm 834×325×258
Weight kg 8
Gross Weight kg 11
Operation Sound dBA
H38383939
M32323333
L25252626
Heat Insulation Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
Gas mm
φ
9.5
φ
12.7
Drain mm
φ
18.0
Drawing No. 3D029436 3D029437
