Printed Circuit Board Connector Wiring Diagram and Name Si18-201
64 Printed Circuit Board Connector Wiring Diagram and Name
1.3 FTK25 / 35J Series, FTX25 / 35J Series,
FTXD25 / 35K Series, FVX25 / 35K Series
Cooling Only FTK25 / 35JVE (A) 9, FTK25 / 35JVEC, FTK25 / 35JAVET
Heat Pump FTX25 / 35JVEA9, FTX25 / 35JVEC, FTX25 / 35JAVET, FTX25 / 35JAV1NB,
FTXD25 / 35KZV1B, FVX25 / 35KZV1B
Printed Circuit
Board
Printed Circuit Board (1) (Control PCB)
Printed Circuit Board (2) (Signal Receiver PCB)
Printed Circuit Board (3) (Intelligent Eye Sensor PCB)
Name of Connector
Note: Other designations
1) S1 Connector for Fan Motor
2) S6 Connector for Swing Motor (Horizontal Flap)
3) S7 Connector for Fan Motor
4) S21 Connector for Centralized Control to 5 Rooms
5) S27, S36 Connector for Control PCB
6) S26 Connector for Signal Receiver PCB
7) S32 Connector for Room Temp/Heat Exchanger Thermistor
8) S35 Connector for Intelligent Eye Sensor PCB
1) V1 Varistor
2) JA Address Setting Jumper
JB Fan Speed Setting when Compressor is OFF on Thermostat.
JC Power Failure Recovery Function.
3) SW7 Operation Switch
4) LED1 (GRN) LED for Operation
5) LED2 (YLW) LED for Timer
6) LED3 (GRN) LED for Intelligent Eye
To Next Page
