Installation Si18-201
344 Caution Before Operation
1. Installation
1.1 Outdoor Unit
1 INSTALLATION PROCEDURE
1.Carrying-in
• Take care not to let your hands and other objects touch the rear fins. WARNING
1. Carry in the equipment slowly, using the grips provided on the sides.
• Always use accessory parts or those of designated specification as parts required for installation.
2.Installation service space
* The horizontal coupling and stacking are not allowed.
(A) Where there is an obstacle on the suction side:
• No obstacle above
· Obstacle on the suction side only · Obstacle on both sides
• Obstacle above, too
· Obstacle on the suction side, too · Obstacle on the sunction side, and both sides
(B) Where there is an obstacle on the discharge side:
• No obstacle above
• Obstacle above, too
(Front) (Back)
Discharge grill
GripOutdoor unit
Do not grab the inlet hole section
on the casing, or it may be
deformed.
Hold the casing edges.
100 or more
100 or more
100 or more
100 or more
5
00
or less
1000 or more
100 or m
ore
500 or less
1000 or more
150 or m
ore
150 or more
150 or more
500 or more
500 or less
1000 or more
500 or more
