Specifications Si18-201
42 Specifications
"
Ceiling Mounted Cassette Type (SkyAir)
"
Duct Connected Type (SkyAir)
★
Refer to Engineering Data Book.
50Hz 220V
Model
FHYC35KV1C9 FHYC50KV1C9 FHYC60KV1C9 FHYC71KV1C9
Cooling Heating Cooling Heating Cooling Heating Cooling Heating
Rating Capacity 3.75 4.22 5.2 5.8 6.15 7.0 7.7 7.9
Front Panel Color White White
Air Flow
Rates
m³/min
H 14.0 15.0 19.0
L 10.0 11.0 14.0
cfm
H 494 530 671
L 353 388 494
Fan
Type Turbo Fan Turbo Fan
Motor Output W 45 45
Speed Steps 2 Steps and Auto 2 Steps and Auto
Air Filter Resin Net (with Mold Resistant) Resin Net (with Mold Resistant)
Running Current
★
(Rated) A 0.8 0.9
Power Consumption
★
(Rated) W 140 161
Power Factor
★
% 79.5 81.3
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 230×840×840 230×840×840
Package Dimensions mm 305×930×920 305×930×920
Weight kg 24 24
Gross Weight kg 29 29
Operation Sound dBA
H33 35
L29 30
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
φ
6.4
φ
9.5
Gas mm
φ
12.7
φ
15.9
φ
15.9
Drain mm
φ
25
φ
25
50Hz 220V
Model
FDYM60FAV1C FDYM03FAV1C
Cooling Heating Cooling Heating
Rating Capacity 6.0 7.0 7.7 7.9
Front Panel Color —
Air Flow
Rates
m³/min
H 20.0
L —
cfm
H 706
L —
Fan
Type Sirocco Fan
Motor Output W 125
Speed Steps 2 Step and Auto
Air Filter —
Running Current
★
(Rated) A 0.9
Power Consumption
★
(Rated) W 170
Power Factor
★
% 85.9
Temperature Control Microcomputer Control
Dimensions (H×W×D) mm 295×1,100×680
Package Dimensions mm 349×1,311×864
Weight kg 42
Gross Weight kg 54
Operation Sound dBA
H39
L —
Heat Insulation Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
φ
9.5
Gas mm
φ
15.9
Drain mm 3/4B
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
