Dalsa S3-10-01k40-R User Manual

46 Spyder 3 CL User's Manual
03-032-20008-00 DALSA
Setting Baud Rate
Purpose: Sets the speed in bps of the serial communication port.
Syntax:
sbr m
Syntax Elements:
m
Baud rate. Available baud rates are: 9600 (Default), 19200,
57600, and 115200.
Notes:
•
Power-on rate is always 9600 baud.
•
The rc (reset camera) command will not reset the camera to
the power-on baud rate and will reboot using the last used
baud rate.
Example:
sbr 57600
Select Cable
Purpose: Sets the cable parameters.
Syntax:
scb i
Syntax Elements:
i
Output compare value. Available values are: 0 to 255.
Notes:
•
In medium configuration, both cables must be the same length.
•
Only one copy of this setting is saved in the camera (rather than
with each setting).
•
On the lfs (load factory settings) command the cable length will
be set to the factory default of 100.
•
The cable parameter is a relational value. Increase the value for
longer cables, and decrease it for shorter ones.
•
Adjust the value until the test pattern (svm 1) is clean.
Example:
scb 75
Cable Length/Type
Use the scb command to select the correct cable parameter for the cable length.
select cable scb i Sets the cable parameter. Increase this value
for longer cables and decrease the value for
shorter cables.
get scb Returns cable parameter.
