Spyder 3 CL User's Manual 85
DALSA 03-032-20008-00
Syntax Parameters Description
get ssm
Returns the current sensitivity mode where:
0 = Low sensitivity mode
1 = High sensitivity mode
2 = Tall pixel mode
get sut
Returns the current upper threshold value.
get svm
Returns the current video mode.
0: Normal video mode
1: Test pattern
2: Test pattern
get ugr
t
Returns the gain reference value.
t = tap selection, either 1 to 2 depending on camera
model, or
0 for all taps
get vt
Returns the camera’s internal chip temperature in degrees
Celsius.
get vv
Returns the camera’s supply voltage.
get wfc
Returns whether FPN coefficients have been saved.
0 = No FPN coefficients saved
1 = Pixel coefficients have been saved
get wpc
Returns whether PRNU coefficients have been saved.
0 = No PRNU coefficients saved
1 = Pixel coefficients have been saved
get wus
Returns whether user settings have been saved.
0 = No user settings saved
1 = User settings have been saved
7.16 ASCII Commands: Reference
The following table lists all of the camera’s available ASCII commands. Refer to
Appendix A for detailed information on using these ASCII commands.
Table 17: Command Quick Reference
Mnemonic Syntax Parameters Description
correction calibrate fpn
ccf
Performs FPN calibration and
eliminates FPN noise by subtracting
away individual pixel dark current.
Parameters:
t = tap id
i = integer value
f = float
m = member of a set
s = string
x
= pixel column number
y = pixel row number
