Spyder 3 CL User's Manual 5
DALSA 03-032-20008-00
1 Introduction to the
Spyder 3 CL Camera
1.1 Camera Highlights
Features
• Broadband responsivity up to 408±16DN(nJ/cm
2
) @10dB gain
• 1024 or 2048 pixels, 14µm x 14µm pixel pitch, 100% fill factor
• Up to 68kHz line rates
• Dynamic range up to 1400:1
• Data transmission exceeding 10m
• ±50µm x, y sensor alignment
• Base Camera Link configuration (8 or 12 bit data on 1 or 2 taps depending on camera
model)
• RoHS and CE compliant.
Programmability
• Serial interface (ASCII, 9600 baud, adjustable to 19200, 57600, 115200), through
Camera Link™.
• Mirroring and forward/reverse control.
• Programmable gain, offset, exposure time and line rate, trigger mode, test pattern
output, and camera diagnostics.
• Tall pixel, high sensitivity, or low sensitivity mode available.
• Flat-field correction—minimizes lens vignetting, non-uniform lighting, and sensor
FPN and PRNU.
Description
The Spyder 3 CL is also DALSA’s first dual line scan camera. When operating in high
sensitivity (dual line scan) mode, the Spyder 3 CL camera has 3x the responsivity of a
DALSA’s Spyder2 line scan camera.
Applications
