Dalsa S3-10-01k40-R - Setting the Exposure Time; Setting the Line Rate

54 Spyder 3 CL User's Manual
03-032-20008-00 DALSA
Setting the Line Rate
Purpose: Sets the camera’s line rate in Hz. Camera must be operating in
exposure mode 2 or 7.
Syntax:
ssf f
Syntax Elements:
i
Desired line rate in Hz. Allowable values are:
1k 1 tap:
300-36000 Hz
1k 2 tap:
300-68000 Hz
2k 1 tap:
300-18500 Hz
2k 2 tap:
300-36000 Hz
Notes:
•
To read the current line frequency, use the command gcp or
get ssf.
•
If you enter an invalid line rate frequency, an error message is
returned.
Related Commands:
sem, set
Example:
ssf 10000
Setting the Exposure Time
Purpose: Sets the camera’s exposure time is µs. Camera must be operating in
mode 2, 6, or 8.
Syntax:
set f
Syntax Elements:
i
Desired exposure time in µs. Allowable range is 3 to 3300µs.*
Notes:
•
To read the current line frequency, use the command gcp or
get set.
•
If you enter an invalid line rate frequency, an error message is
returned.
•
*The exposure time range is based on the current line rate.
•
To determine the maximum exposure time allowed for the
current line rate, use the command
get ger.
Related Commands:
sem, ssf
Example:
set 400.5
Setting the Mirror Mode
Purpose: Sets the camera’s mirror mode. Set the pixel readout as either left to
right, or right to left.
Syntax:
smm i
Syntax Elements:
i
0
: Pixels readout left to right (1 to 512 or 1024 or 2048).
1: Pixels readout right to left (2048 or 1024 or 512 to 1).
Notes:
•
i
Applies to Modes 2 and
7
i
Applies to Modes 2 and
8
