6 Spyder 3 CL User's Manual
03-032-20008-00 DALSA
The Spyder 3 CL camera is ideal for:
• FPD inspection
• Pick and place
• Container inspection
• Wood/tile/steel inspection
• 100% print inspection (lottery tickets, stamps, bank notes, paychecks)
• Postal sorting
• Glass bottle inspection
• Industrial metrology
• Food inspection
• Web inspection
Models
The Spyder 3 CL camera is available in these models.
Table 1: Spyder 3 CL Camera Models Overview
Model Number Description
S3-20-01K40-
00-R
1k resolution, 2 sensor taps. Base Camera Link configuration
S3-20-02K40-
00-R
2k resolution, 2 sensor taps. Base Camera Link configuration
S3-10-01K40-
00-R
1k resolution, 1 sensor tap. Base Camera Link configuration
S3-10-02K40-
00-R
2k resolution, 1 sensor tap. Base Camera Link configuration
1.2 Camera Performance Specifications
Table 2: Spyder 3 CL Camera Performance Specifications
Feature / Specification Units 1k 2k Notes
Imager Format dual line scan dual line scan
Resolution pixels 1024 2048
Pixel Fill Factor % 100 100
Pixel Size µm 14x14 14x14
Sensitivity Mode High, low, or
tall pixel
High, low, or
tall pixel
Antiblooming 100x 100x
Gain Range dB ±10 ±10
