Dalsa S3-10-01k40-R User Manual

Spyder 3 CL User's Manual 7
DALSA 03-032-20008-00
Feature / Specification Units 1k 2k Notes
Optical Interface Units Notes
Back Focal Distance
M42x1 mm 6.56±0.25
Lens mount
adapters are
available.
Contact Sales for
more
information.
Sensor Alignment
x
y
z
0z
µm
µm
mm
°
±50
±50
±0.25
±0.2
Mechanical Interface Units Notes
Camera Size mm 72(h) x 60(l) x 50(w)
Mass g <300
Connectors
power connector
data connector
6 pin male Hirose
MDR26 female
Electrical Interface Units Notes
Input Voltage Volts +12 to +15
Power Dissipation W <5
Operating Temperature °C 0 to 50
Bit Width Bits 8 or 12 bit user selectable
Output Data Configuration Base
Camera Link
Speed 1k 2k Notes
Maximum Line Rate 2 tap model 68 36 80 MHz
1 tap model 36 18.5 40 MHz
Operating Specifications (12 bit values, Flat Field Correction enabled)
-10dB 0dB +10dB Specification Unit
Min Typ Max Min Typ Max Min Typ Max Notes
Broadband
Responsivity (dual
line)
DN/nJ/cm
2
38.8 40.8 42.8 124 129 134 392 408 424
Broadband
Responsivity (single
line)
DN/nJ/cm
2
20.4 62 204
Random Noise rms DN 8 19.2 24 60 76.8
Dynamic Range
(Dual Line)
ratio 500:1 1400:1 203:1 324:1 59:1 108:1
Dynamic Range
(Single Line)
ratio 500:1 1400:1 203:1 324:1 59:1 108:1
FPN Global

Dalsa S3-10-01k40-R Specifications

General

Brand	Dalsa
Model	S3-10-01k40-R
Category	Digital Camera
Language	English
