Dalsa S3-10-01k40-R User Manual

8 Spyder 3 CL User's Manual
03-032-20008-00 DALSA
Operating Specifications (12 bit values, Flat Field Correction enabled)
-10dB 0dB +10dB Specification Unit
Min Typ Max Min Typ Max Min Typ Max Notes
Uncorrected
Corrected
DN
DN
52.8
32
169.6
32
536
64
PRNU ECD
Uncorrected Local
Uncorrected Global
Corrected Local
Corrected Global
%
%
DN p-p
DN p-p
8.5%
10%
80
80
8.5%
10%
80
80
8.5%
10%
95
95
1
PRNU ECE
Uncorrected Local
Uncorrected Global
Corrected Local
Corrected Global
%
%
DN p-p
DN p-p
8.5%
10%
80
80
12%
12%
208
208
37%
37%
752
752
SEE (calculated)
Dual line
Single line
nJ/cm
2
6.75
13.5
2.14
4.29
0.68
1.35
NEE (calculated)
Dual line
Single line
pJ/cm
2
13.6
27.2
10.3
20.8
10.2
20.4
Sat. Output
Amplitude
DN 3968±80
DC Offset DN 96 160 336
Test conditions unless otherwise noted:
• CCD Pixel Rate: 40 Megapixels/second per sensor tap
• Line Rate: 5000 Hz
• Nominal Gain setting unless otherwise specified
• Light Source: Broadband Quartz Halogen, 3250k, with 750 nm highpass filter
installed
• Ambient test temperature 25 °C
• Unless specified, all values are referenced at 12 bit
• Exposure mode disabled.
• Unless specified, dual line mode.
Notes
1. PRNU measured at 50% SAT.

Dalsa S3-10-01k40-R Specifications
