90 Spyder 3 CL User's Manual
03-032-20008-00 DALSA
Mnemonic Syntax Parameters
Description
set analog offset
sao
t i
Sets the analog offset.
t = tap selection, either 1 or 2
depending on camera model, or
0 for
all taps.
i= Offset value in a range from 0 to
255 (12-bit LSB). Offset increases with
higher values.
set binning horizontal
sbh
m
Sets the horizontal binning value.
Available values are
1 and 2.
set baud rate
sbr
i
Set the speed of camera serial
communication port. Baud rates:
9600,
19200, 57600, and 115200. Default:
9600.
set cable parameter
scb
i
Set the cable parameter. Output
compare value. Available values are: 0-
255.
set ccd direction
scd
i
Sets the CCD shift direction where:
0 = Forward CCD shift direction.
1 = Reverse CCD shift direction.
2 = Externally controlled direction
control via CC3.
set digital offset
sdo
t i
Subtracts the input value from the
video signal prior to FPN correction.
t = tap selection, either 1 or 2
depending on camera model, or
0 for
all taps.
i = Offset in a range from 0 to
2048DN.
set exposure mode
sem
m
Sets the exposure mode:
2 = Internal SYNC, internal PRIN,
programmable line rate and exposure
time using commands
ssf and set
3 = External SYNC, internal PRIN,
maximum exposure time
4 = Smart EXSYNC
5 = External SYNC and PRIN
6 = External SYNC, internal PRIN,
programmable exposure time
7 = Internal programmable SYNC,
maximum exposure time. Factory
setting.
8 = Internal SYNC, internal PRIN,
programmable exposure time.
Maximum line rate for exposure time.
set exposure time
set
f
Sets the exposure time. Refer to the
camera help screen (
h command) for
allowable range.
