2. DALUM CO2 Recovery Unit
2.1 Description of the Unit
The CO
2
Recovery unit from Dalum Beverage Equipment is a sustainable and compact solution
for craft breweries to generate their own CO
2
from the fermentation of their craft beers. The
CO
2
-Recovery plant produces from 0 kg/h up to 15 kg/h of liquid CO
2
based on your
requirements.
The Craft Breweries need to connect the CO
2
feed gas line, electrical power, water, coolant, and
the CO
2
-Recovery plant will deliver pure CO
2
> 99.9 % v/v at the outlet of the plant.
The CO
2
-Recovery plant consists of a multistage oil free compressor, fluid pumps, low-pressure
scrubber, dehydrators, heat exchangers, reboiler, solenoid valves, water separators, carbon
filter, control panel, level, pressure and temperature sensors as well as a dewpoint sensor. To
protect the plant against overpressure, the machine is equipped with pressure relief valves.
The plant is smart enough to run in an automatic mode. It is programed to run is specific
conditions, in safe and efficient mode.
2.2 Technical Data
Output Capacity
From 0 to 15 kg/h CO
2
at 35-40 bar
Purity
According to EIGA food grade CO
2
specification but improved
to 99,98% CO
2
purity.
Electric Power Consumption
2.5 kw
Voltage
3-phase 400Vac + N +PE
Frequency
50 Hz
Rated Current
10 A
Pressure
Up to 46 bar
Weight
350 kg
Dimensions (L x W x H)
1000 X 1000 X 2900 mm
Sound level
Below 70 dB
Control
PLC with B/W screen
Coolant connection
Min 1.5 bar pressure difference, -2 ±3°C, ½ inch connection
Water supply connection
Min 1 bar, maximum temperature 10°C, ½ inch connection
