Mains Supply 3x200-240 V AC
-
Normal overload
110% for 1 minute
IP20/Chassis
(B3+4 and C3+4
may be converted to IP21 using a conversion kit. (See
also items Mechanical mounting and IP21/Type 1 Enclosure kit in the
Design Guide.))
B3 B3 B3 B4 B4
IP21/NEMA 1 B1 B1 B1 B2 C1
IP55/Type 12 B1 B1 B1 B2 C1
IP66/NEMA 4X B1 B1 B1 B2 C1
Frequency converter
Typical
Shaft Output
[kW]
P5K5
5.5
P7K5
7.5
P11K
11
P15K
15
P18K
18.5
Typical Shaft Output [HP] at 208 V 7.5 10 15 20 25
Output current
Continuous (3 x 200-240 V) [A] 24.2 30.8 46.2 59.4 74.8
Intermittent (3 x 200-240 V) [A] 26.6 33.9 50.8 65.3 82.3
Continuous kVA (208 V AC) [kVA] 8.7 11.1 16.6 21.4 26.9
Max. input current
Continuous (3 x 200-240 V) [A] 22.0 28.0 42.0 54.0 68.0
Intermittent (3 x 200-240 V) [A] 24.2 30.8 46.2 59.4 74.8
Additional Specifications
Estimated power loss at rated max. load [W]
4)
269 310 447 602 737
IP20 max. cable cross-section (mains, brake, motor and load sharing) 10, 10 (8,8-) 35,-,- (2,-,-) 35 (2) 50 (1)
IP21, IP55, IP66 max. cable cross-section (mains, motor) [mm
2
/AWG]
10, 10 (8,8-)
35, 25, 25
(2,
4, 4)
50
(1)
IP21, IP55, IP66 max. cable cross-section (brake, load sharing) [mm
2
/AWG]
16, 10, 16 (6, 8, 6)
35,-,- (2,-,-)
50 (1)
Weight enclosure IP20 [kg] 12 12 12 23.5 23.5
Weight enclosure IP21 [kg] 23 23 23 27 45
Weight enclosure IP55 [kg] 23 23 23 27 45
Weight enclosure IP66 [kg] 23 23 23 27 45
Efficiency
3)
0.96 0.96 0.96 0.96 0.96
Table 10.2 Mains Supply 3x200-240 V AC
Specifications
VLT
®
HVAC Drive Operating Instructions
MG11AI02 - VLT
®
is a registered Danfoss trademark
67
10 10
