Danfoss 102 User Manual

Mains Supply 3x200-240 V AC
-
Normal overload
110% for 1 minute
IP20/Chassis
(B3+4 and C3+4
may be converted to IP21 using a conversion kit. (See also
items Mechanical mounting and IP21/Type 1 Enclosure kit in the Design Guide.))
C3 C3 C4 C4
IP21/NEMA 1 C1 C1 C2 C2
IP55/Type 12 C1 C1 C2 C2
IP66/NEMA 4X C1 C1 C2 C2
Frequency converter
Typical
Shaft Output
[kW]
P22K
22
P30K
30
P37K
37
P45K
45
Typical Shaft Output [HP] at 208 V 30 40 50 60
Output current
Continuous (3 x 200-240 V) [A] 88.0 115 143 170
Intermittent (3 x 200-240 V) [A] 96.8 127 157 187
Continuous kVA (208 V AC) [kVA] 31.7 41.4 51.5 61.2
Max. input current
Continuous (3 x 200-240 V) [A] 80.0 104.0 130.0 154.0
Intermittent (3 x 200-240 V) [A] 88.0 114.0 143.0 169.0
Additional Specifications
Estimated power loss at rated max. load [W]
4)
845 1140 1353 1636
IP20 max. cable cross-section (mains, brake, motor and load sharing) 150 (300 MCM)
IP21, IP55, IP66 max. cable cross-section (mains, motor) [mm
2
/AWG]
150 (300 MCM)
IP21, IP55, IP66 max. cable cross-section (brake, load sharing) [mm
2
/AWG]
95 (3/0)
Weight enclosure IP20 [kg] 35 35 50 50
Weight enclosure IP21 [kg] 45 45 65 65
Weight enclosure IP55 [kg] 45 45 65 65
Weight enclosure IP66 [kg] 45 45 65 65
Efficiency
3)
0.97 0.97 0.97 0.97
Table 10.3 Mains Supply 3x200-240 V AC
Specifications
VLT
®
HVAC Drive Operating Instructions
68 MG11AI02 - VLT
®
is a registered Danfoss trademark
1010
